Structured Cabling

With Al Yamin structured cabling technology, we can provide the highest performing, standards-based copper and fiber solution available. Our structured cabling infrastructure systems will ensure optimum performance and flexibility and provide the longest possible life span before re-cabling or upgrading will be required. In a constantly changing business landscape, you need fiber cabling that can stand the test of time. Don't let an outdated wiring system keep you from adapting to modern network advancements. Technology is moving at lightning speeds and so should your cabling options.

If you are relocating or upgrading, you will want the latest infrastructure system in order to address the changing needs of your computer network and to remain ahead of your competition for years to come. Al Yamin provides the highest quality, best performing structured cabling systems available and can build an Ethernet infrastructure to serve your strategic business needs for the future.

The Al Yamin is recognized as a technology leader in the telecommunications industry and a world-class supplier of technologically advanced standards-based structured cabling systems including data cabling and voice cabling services, copper and fiber network products plus network cabling rack systems in UAE.

Al Yamin was one of the first structured cabling company in UAE to deliver CAT 6a, a high bandwidth network cabling solution, and also the first to deliver the next step in structured cabling solutions, Category 7/ Class F (7A/FA) TERA. As Al Yamin cabling systems are based upon globally recognized standards, Al Yamin provides a guide to network cabling standards as a service to customers. This includes information on Preferred Cable Terminology plus details about how ISO, TIA and other organizations define standards-based components and structured cabling systems.

Al Yamin is a one-stop network cabling solution provider with the resource to design and implement structured cabling in UAE. Providing network cabling service throughout a business involve cable laying, installation of the Connectors, Faceplates, Network cabinets and Testing of cables. We offer reliable connectivity back born for your company that allows proper data transfer. We always use good quality cables from structured cable brands in UAE.

We believe in the value and power of more sophisticated fiber optic wiring and network infrastructure. Whether your company needs an updated structured cabling solution, brand new fiber optic network capabilities, or delicate splicing to existing network wiring, Al Yamin can provide you high-quality cabling work in a timely fashion.

Future-proof your network wiring with structured, up-to-date, adaptable, and streamlined fiber optic cabling from Al Yamin. The preferred structured network cabling installation company in UAE, we works to make sure that your business in Dubai and Sharjah has affordable and high-quality fiber optic cabling solutions, tailor fitted to your current and future needs.

Since the structured cabling infrastructure is the most critical part of your voice and data network, choosing a qualified voice and data cabling provider is a critical decision. Al Yamin installs all of its projects to TIA/EIA-568 C, IEEE and BICSI standards with certified installers. We use only high-end quality products in our structured wiring solutions, which are backed by manufacturer warranties. Our goal is to provide our customers with a physical layer infrastructure capable of supporting all applications designed in conjunction with today's standards. By taking time to listen, study your business and understand your goals, Al Yamin can install a complete voice and data cabling solution with service and support during and after the installation.

Our solutions include:

Design: We specialize in recommendations for new construction or your existing facility that will meet your voice and data network cabling requirements.
Installation: Our installation team is trained and certified by our manufacturers and BISCI to provide the highest quality structured cabling installation.
Testing & Certifications: Your structured cabling network will be tested and certified to manufacturer and BISCI standards. Our technical team uses FLUKE cable analysers to test and certify your copper and fiber network cabling.
Documentation: Labelling of faceplates and patch panels is completed using 606-B labelling standard. A drawing which reflects the cable locations and pathway can be created and provided. This allows ease in locating each cable and point of termination.

Category 5e: Commonly referred to as "Cat 5e" is a twisted pair cable type designed for high signal integrity. It is often used in cabling for computer networks and is also used to carry basic voice services.

Category 6: Commonly referred to as "Cat 6" it is used to carry Ethernet 10Base-T, 100Base-TX, and 1000Base-T (Gigabit Ethernet) connections. Cat 6 cable is backed with more stringent specifications for crosstalk and system noise than earlier cabling standards. While the speeds are faster for Cat6 on shorter runs, the downside is that the wires are stiffer making them more difficult to bend, and the thicker wires are more difficult to terminate.

Category 6a: Commonly referred to as "Cat6a or Cat6 Augmented or 10gig" is the latest standard for enhanced performance standards for twisted pair cable systems. Category 6a is defined at frequencies up to 500MHz twice that of Cat 6. Category 6a performs at improved specifications, in particular in the area of alien crosstalk as compared to Cat 6 UTP (unshielded twisted pair), which exhibited high alien noise in high frequencies. The speeds of Cat6a are 10 Gbps, but the difference is that these lightening speeds are maintained across longer distances of up to 100 meters. These thicker cables with their better shielding are ideal for industrial situations, but lack flexibility that is often needed for a residential deployment.

Category 7 / Class F: The latest "cable on the block" is Cat7, which is shielded, and requires a GigaGate45 connection. The speeds are wickedly fast, at shorter distances, maxing out at 100 Gbps at < 15 meter distances, and reverting to 10 Gbps at longer distances. There is also a Cat8 standard that is still being finalized, but no gear is currently available, with a targeted throughput of 40 Gbps at longer distances. These "next generation" cable choices of Cat7 and above are more suited to data centers, than residential applications.

Multi-Mode Fiber: Best suited for premise applications where links are less than 1000 meters for 100MB/s or less, 550 meters for data rates of 1GB/s or less, and 300 meters for data rates of 10GB/s or less. There are two types of multi-mode fiber, 62.5 um and 50 um. Our Taylored team can help determine the right type for you.

Single-Mode Fiber: Best suited for bandwidth requirements exceeding multi-mode’s capability, distances exceeding multi-mode’s capability and where the application dictates single mode like video.

Al Yamin provide a robust, cost-effective enclosure solution that provides valuable space on each side of the equipment rails for cable management, PDU mounting or connectivity. All of these features are integrated into a full-featured modular enclosure that is equally effective as a standalone network and server cabinet or in a multi-unit bayed configuration.

Racks & Cabinets: A cabinet or rack is standardized system for mounting phone or data modules in a "stack" or rack. Equipment designed to be placed in a rack or cabinet is typically described as rack mount, a rack-mounted system, a rack-mount chassis, rack mountable, or occasionally simple shelf.
Patch Panels: A panel, typically rack-mounted that houses cable connections. Angled patch panels are available to help conserve space.
Wire Manager: Providing a neat and clean appearance by managing and hiding cables and patch cords in cabinets and racks. Cable Tray: Either basket tray or ladder rack styles are available to allow for convenient installation of current and future cabling projects.

Being one of the most trusted data and voice cabling companies in Dubai, it is our job at Al Yamin to provide companies with exceptional quality structured cabling services. We make a constant effort to increase and maintain a standard of quality both with our products and our services. Not only does a well designed and expertly installed cabling system increase efficiency and breed productivity, it also reduces company costs significantly. Our services are geared towards providing a complete solution for all business requirements.

Planning and installation of structured cabling.
Moving structured cabling to new locations and adapting accordingly.
Making all kinds of custom addition and expansion of existing structured cabling systems.
Making changes in the plan level of cabling to improve and increase functionality of structured cabling.
Administration of structured cabling.
Maintenance and repair of structured cabling.

With these cutting edge services, our company has taken structured cabling systems to a whole new level. We take care of all communication requirements, including requirements for voice calls, video calls, conferencing and reliable and secure data transfer. Our services include planning, expert installation, implementation of cabling designs, extensive documentation regarding the use of cabling systems and testing equipment which enables you to periodically check your system for errors and flaws. These services give us a considerable edge over most other structured cabling companies in UAE.

We are highly experienced at providing total maintenance care plan to meet your explicit network cabling needs in UAE. As an experienced provider in the IT and Telecom industry, you can expect the highest level of response to any of the network system issues. We provides structured cabling services in the following areas:

Structured cabling: Data, Voice, Video
Cat5e, Cat6, Cat6a, Cat7, Fiber
Cable Plant Certification
Design and Build
Consulting and Project Management
